Description
Description
- Spraying distance up to 8-10 meters.
- Have total flexibility and maneuverability.
- High-quality material, good effect, and long service life.
- Applicable for DJs, bands, bars, pubs, clubs, skating rinks, KTV, family parties, birthdays, celebrations, weddings, and festivals.
Technical Parameter
- Specification :
Control Mode: DMX512/Electronic Control
Channels DMX512
Voltage: AC110V / 220V, 60Hz / 50Hz
Power: 30W
Spray height: 8-10 meters
Maximum pressure: 1400Psi
Hose length: 6 meters custom length available with quick connector
Angle: Adjustable from 0 to 90 degrees
Product Warranty Time: 1 year
Packaging Shape: Cardboard box with foam inside
Product dimensions: 27*20*39 cm
Packaging dimensions: 30*30*42 cm
Product weight: 5.2 kg
Shipping weight: 8 kg
- Packing Include :
1pc CO2 jetting machine
1pc 6-meter gas hose
1pc 2-meter DMX cable
1pc Power cable
1pc Manual book
How To Use
- INSTALLATION：
1. Place the large CO2 column in the corresponding position.
2. Connect the CO2 hose to the gas bottle.
3. Place the bottle and keep it flat.
4. Connect the machine with the gas bottle through the hose, the hose on one side connects to the tank, and the other side connects to the machine.
5. Connect the valve of the gas bottle.
6. Connect the machine and the console.
7. Before disassembling, first turn off the bottle valve, let out the gas remaining in the tube, then turn off the power, and finally separate the gas bottle connector.
- Steps To Use :
1. Electric control: The operation of the machine is very simple Connect the CO2 cannon to the electric control button, Then connect the machine to the CO2 gas tank via a high-pressure hose Switch the machine to the "ON" position, and open the valve of the cylinder. Press the control button, the machine will spray.
2. DMX512 control: Connect the CO2 jet cannon to the power supply via the power cable, and DMX to the DMX controller via the DMX cable. Then connect the machine to the CO2 gas tank via a high-pressure hose. The machine has 6 channels. After setting the DMX address, operate your console, The machine will spray and change the effects of the LED.
3. To ensure that the machine parts have a normal service life. it is recommended to control the continuous spraying time at about 10 seconds each time When the machine is not needed, and if the high-pressure pipe needs to be removed. it needs to be sure to turn off the gas cylinder switch first, and then evacuate the residual gas in the machine before removing the tube, otherwise, either end of the tube and the gas cylinder cannot be pulled out.
Shipping
- U.S. warehouse: 2-5 working days to U.S., 7-12 working days to other areas.
- Spain warehouse: 2-4 working days to Spain, 7-12 working days to other EU regions.
- Poland warehouse: 2-4 working days to Poland, 7-12 working days to the rest of the EU.
- China warehouse: 7-20 working days for direct shipment from China.
- The transportation type depends on the region, and it is uniformly displayed as international shipping.
- The goods will be sent out within 1-5 working days. After the logistics order number is generated, customer service will send an email to notify you. Please pay attention to the delivery status.
- If you have any questions, please leave a message.
Q&A
- Q: How long can the trachea be customized?
A: The length can be customized according to your needs. The longest is generally not recommended to be over 35 meters, but we also have customers who have made a length of about 50 meters, because the longer the pipe, the more gas will be used in the pipe during use. This will waste more gas and affect the use effect.
- Q: How is the effect, can I jet against people, will it have any effect?
A: Yes, but it has a safe distance. Please always ensure that no one is within 3 meters of the CO2 column machine in the direction of injection.
- Q: Where to buy carbon dioxide gas?
A: This gas can generally be purchased at your local store.
- Q: How long can an air column gun spray and can it continue to spray?
A: The gas column machine can not continue jetting. If the jetting time is too long and the air pressure is too high, the valve may be damaged. In order to ensure that the machine parts have a normal service life, we recommend that each jet be controlled for about 10 seconds, it takes 5 seconds in the middle to blow again. This way, you can avoid damage to the accessories due to improper operation.
- Q: How long is your product warranty? If it’s a quality problem, who undertakes the freight out and home?
A: 1 year. If the machine is damaged and fails, please contact customer service the first time, and provide your purchase order number, and the video or appearance photos of the product work. we will start the after-sales maintenance service for you, and help you to repair the machine perfectly. During the warranty period, replacement parts are shipped free of charge. For detailed information please refer to the Return Policy.
- Q: Is there any requirement for the gas used?
A: Generally, the 40L gas cylinders used in our factory are about 6.5-7 pressures, and the pressure will rise again under high-temperature conditions. It can fill up to 24 kg of gas. Generally, it is 23KG, but not less than 18KG. You can refer to these values.
-
Q: Is there a relevant certificate?
A: Yes, all of our products are CE, FCC, and ROSH certified and can be exported.
- Q: What to do if the machine does not blow air?
A: Please provide the video and we will give feedback to our technical department to see if we can guide you to solve the problem. If there is no way, you need to return the machine to the factory for maintenance.
- Q: Why is the gas emitted by our machine sometimes big and small?
A: Please describe the specific situation and we will give feedback to our technical department to see if we can guide you to solve the problem. If there is no way, you need to return the machine to the factory for maintenance.
