Description
Description
This lightweight and powerful 150W Led 3in1 gobo beam moving head is perfect for club venues looking to blast colorful yet intense narrow beams to create spectacular mid-air aerial effects.
The E-Beam houses a separate Gobo and Color Wheel Including 9 Colors plus White and rainbow effect, and 10 Gobos plus Open; with rotation and running water effect, this fixture will create a multitude of colorful long-throw aerial beam effects. The electronic Dimmer, Strobe, and adjustable speed for the strobe effect add endless possibilities combined with its 3 facet prism with bi-direction rotation.
Technical Parameter
Specification:
Category | Specification |
---|---|
Voltage | AC100-240V, 50/60Hz |
Power | 280W |
LED Source | 150W White LED |
Color Temperature | 7500K-8000K |
LED Life Time | 50,000 Hours |
Channel | 18 DMX channels |
Control | DMX / Master-slave / Auto / Sound activated |
Pan | 540 degrees + fine |
Tilt | 270 degrees + fine |
Zoom Range | 8-17° |
Dimmer | 0-100% smooth linear dimmer |
Strobe | 1-25 Hz with pulse effect |
Color Wheel | 9 colors + open, with a rainbow effect |
Static Gobo Wheel | 10 gobos + open, with rotation and running water effect |
Rotation Gobo Wheel | 6 gobos + open |
Prism | 3-facet prism with bi-directional rotating |
Frost | With frost effect |
Display | LCD, adjustable 180 degrees |
Product Size | 27.5 × 20 × 47.5 cm |
Packing Size | 47.5 × 36.5 × 360 cm (1PC/CTN) |
Net Weight (N.W.) | 9 kg |
Gross Weight (G.W.) | 12 kg |
- Please Note:
We have different power supply plugs, United Kingdom plugs, AU plugs, EU plugs, and USA plugs, please let us know the power supply you need, or we will choose everything according to your country.
How To Use
1. To ensure the product's service life, this product should not be placed in a humid or leaking place, and it should not work in a place where the temperature exceeds 40°C.
2. Do not place this product where it is easy to loosen or vibrate.
3. To avoid the danger of electricity, the maintenance of this product requires professional maintenance personnel.
4. The power supply voltage change should not exceed ±10% when the light bulb is working. If the voltage is too high, the service life of the light bulb will be shortened. If the voltage is too low, the light efficiency will be affected.
5. After the power is cut off, the lamps need to be fully cooled before being powered on again.
Maintenance
1. The lamp should be kept dry and avoid working in a humid environment.
2. Indirect use will effectively prolong the service life of the lamp.
3. To obtain a good ventilation effect and lighting effect, it is necessary to pay attention to cleaning the fan and lens frequently.
4. Do not wipe the lamp housing with organic solvents to avoid damage
Shipping
- China warehouse: 7-20 working days for direct shipment from China.
- The transportation type depends on the region, and it is uniformly displayed as international shipping.
- The goods will be sent out within 1-5 working days. After the logistics order number is generated, customer service will send an email to notify you. Please pay attention to the delivery status.
- If you have any questions, please leave a message.
Q&A
- Q: Will the light fixture work without a DMX console?
-
A: Yes, don’t worry! In addition to DMX control mode, all moving headlights also have self-propelled, sound-activated, manual, and other modes.
When there is no DMX console control, you can choose the music sound control mode and the effect is very good.
- Q: If the lamp is broken during the warranty period, how do you operate it?
-
A: You can rest assured that we have more than 8 years of export experience, and we provide free technical consultation throughout our life.
Moreover, we have a professional after-sales team that can give you information to respond to communication within 1 hour, and give you solve solution within 8 hours to help you deal with after-sales problems; but We need your active cooperation and feedback. You can give us feedback on the problem by taking videos and photos, as well as the description of the problem during the operation of the light; we need to confirm which part may be broken, and then we will guide you on how to do with step by step, if the problem is more complicated, we also have operation videos to provide guidance; if it still does not work, we will send you the free accessories for replacement, and you only need to pay the freight.
- Q: After the shelf life, how to ensure the stability of the light?
- A: If the product has passed the warranty, we will provide free technical consultation for life. Even after the warranty period, we recommend that customers do regular maintenance and maintenance of the lamps; if there is any problem with the product outside the warranty period, you can describe the problem, shoot videos and pictures, and we will provide you with the corresponding accessories for repairs. You need it here. Bear the cost of accessories and transportation.
