Description
Description
- 6 Head RGB animation laser matrix. Built-in nearly 200 patterns and beam effects.
- Individual control of each head (such as pattern, effect, color, brightness, and position control) can be realized through the console, to combine the same effect or different super shocking effects.
- Dust-proof structure design. The protection level reaches IP61 level, which can effectively prevent dust and smoke oil from entering the machine, ensuring the life of the laser and reducing maintenance costs.
- The RGB lasers all use high-stability and long-life semiconductor laser (Diode Solid-State Laser), and the laser diode (Laser Diode) directly emits laser light, and the working environment is -30°C to 40°C.
- The laser adopts TTL modulation mode/Analog Modulation, with bright colors.
Our Advantages:
- The light has a small volume, saves transportation costs, and is easy to move.
- The whole exterior of the light body uses an Aluminum case, which makes the body plane smooth and brings a good tactile impression. What's more, it is less prone to wear and rust.
- The logo was printed by laser, not easy to fall off.
-
Uses an intelligent dual temperature control system—silent fan cooling + semiconductor TEC heat sink.
Technical Parameter
Specification:
Parameter | Description |
---|---|
Voltage | AC 90~250V, 50Hz/60Hz |
Rated Power | 100W~200W |
Waterproof Level | IP61 |
Work Environment | Outdoor and indoor, -30°C to 40°C |
Scanner | 20KPPS, ±20° |
Laser | RGB analog modulation |
Laser Specifications |
Red Laser: >400mW, Wavelength: 638nm Green Laser: >600mW, Wavelength: 520nm Blue Laser: >1000mW, Wavelength: 450nm |
Beam Diameter | <6mm |
Divergence | <1.5mrad |
Working Modes | DMX512 (Normal mode 12CH/ Expert mode 62CH), MUSIC (Sound Active) Mode, AUTO Mode, ILDA Mode (optional) |
Safety Configure | Security protection, Laser key switch, laser remote interlock, flying ring bolt |
Machine Dimensions | 100 × 16.7 × 11.5 cm |
Machine Weight | 12 kg |
Gross Weight | 16 kg |
Applicable places: DJs, bands, bars, pubs, clubs, skating rinks, KTV, family parties, birthdays, celebrations, weddings, festivals, shopping malls, stores, stores, and other designated places.
Please Note:
We have different power supply plugs, United Kingdom plugs, AU plugs, EU plugs, the USA plugs, please let us know the power supply you need, or we will choose everything according to your country.
How To Use
The manual will be with the machine, if the manual is missing, please leave a message on the website, and we will contact you as soon as possible
Shipping
- U.S. warehouse: 2-5 working days to U.S., 7-12 working days to other areas.
- Spain warehouse: 2-4 working days to Spain, 7-12 working days to other EU regions.
- Poland warehouse: 2-4 working days to Poland, 7-12 working days to the rest of the EU.
- China warehouse: 7-20 working days for direct shipment from China.
- The transportation type depends on the region, and it is uniformly displayed as international shipping.
- The goods will be sent out within 1-5 working days. After the logistics order number is generated, customer service will send an email to notify you. Please pay attention to the delivery status.
-
If you have any questions, please leave a message.
Q&A
- Q: How to choose a laser light?
A: According to the different usage scenarios, use different power laser lights.
For small parties and family gatherings, 1W, 2W, 3W, 5W, and 6W laser lights can be enough because they are cheap and the operation method is simple.
It is recommended that a bar or club choose a 10W laser light. According to the bar's area, it can be equipped with 2-6 sets of equipment. The 10W laser light can carry out complex requirements such as laser engraving patterns, which can meet all the bar's needs.
For concerts, music festivals, celebrations, and other activities, it is recommended to choose 20W, and 30W laser lights.
For urban outdoor landmarks, it is recommended to choose high-power laser lights, 30W-100W, depending on specific requirements. If you need more professional guidance, please contact our customer service.
- Q: Do your laser lights have a security key?
A: Yes, every laser light has a security key and a standard interlock.
- Q: Do I need to buy FB4?
A: The laser light has a self-propelled mode with various changes, which can meet most usage scenarios. If you need to customize the effect, you can buy FB4 on the local professional website.
Recommended website: https://pangolin.com/
