Description
Description
- 5 Channel Functions.
- Spray distance-Blasts 10-12 meters.
- The CO2 jet machine is compact in size, lightweight, and easy to install.
- This stage CO2 machine adopts a self-developed LCD color screen.
- The air column moving head angle can reach 180 degrees.
Technical Parameter
- Features:
1. Independent research and development design appearance.
2. The machine uses independent research and development of the LCD color screen motherboard.
3. The machine is put on the ground at any angle jet without fixed will not rebound.
4. With electronically controlled point spray function.
5. With electronically controlled long spray function.
- Specification:
Control mode: DMX512 control, line control self-propelled point spray, line control self-propelled long spray.
Voltage: 100-120V 60Hz/200-240V 50Hz
Power: 150W
Jetting distance: 8-10m
Maximum pressure: 1400Psi
Shaking head angle: 180 degrees
Product size: 360/253/283mm
Package size: 44.5/33/32.5cm
Net weight: 10.7kg
Gross weight: 14.6 kg
- Product List:
1pc H-C04 CO2 Jet Machine
1pc Power cable
1pc DMX cable
1pc Resin high-pressure pipe
2pcs Hanging bracket
4pcs screw
1pc Manual book
How To Use
- Install Illustration:
1. Place the large CO2 column in the corresponding position.
2. Connect the CO2 hose to the gas bottle.
3. Place the bottle and keep it flat.
4. Connect the machine with the gas bottle through the hose, the hose on one side connects to the tank, and the other side connects to the machine.
5. Connect the valve of the gas bottle.
6. Connect the machine and the console.
7. Before disassembling, first turn off the bottle valve, let out the gas remaining in the tube, then turn off the power, and finally separate the gas bottle connector.
- Attention:
Before using this product please first read the operating guide. Please follow the instructions to install and use.
Shipping
- U.S. warehouse: 2-5 working days to U.S., 7-12 working days to other areas.
- Spain warehouse: 2-4 working days to Spain, 7-12 working days to other EU regions.
- Poland warehouse: 2-4 working days to Poland, 7-12 working days to the rest of the EU.
- China warehouse: 7-20 working days for direct shipment from China.
- The transportation type depends on the region, and it is uniformly displayed as international shipping.
- The goods will be sent out within 1-5 working days. After the logistics order number is generated, customer service will send an email to notify you. Please pay attention to the delivery status.
-
If you have any questions, please leave a message.
Q&A
- Q: Is it sure that the sprayed gas is free of slag?
A: Yes, there is absolutely no scum. This completely avoids the discomfort caused by scum.
- Q: How many meters can the pipe be equipped with? How long can it be made according to the length I need?
A: A 6-meter tube is provided at random. The length can also be customized according to your needs. The longest is generally not recommended to exceed 35 meters, but we also have customers who have made a length of about 50 meters. Because the longer the tube, the more process the gas occupied in the middle tube, which will waste more gas and affect the use effect.
- Q: The pipe joint of this machine seems to be different from yours.
A: Yes, you have observed it very carefully. The joint used by this machine is the LSQ-S1-03SF 3/8 model, which is different from the joints of our other machines, so the pipe of this machine and other machines cannot be used universally.
- Q: Do you need a cylinder for each of your machines? How big is the cylinder?
A: We generally use 40L gas cylinders. In order to achieve the best results, we recommend one gas cylinder for one machine.
- Q: How long can a 40L cylinder be sprayed?
A: The test can be continued for about 40 seconds under the full pressure of a 40L cylinder.
- Q: What kind of gas is in the cylinder, is it safe and harmful to the human body?
A: Medical grade carbon dioxide is used, which is harmless to the human body, and it is pure and has no odor and impurities. It will not cause the possibility of clogging the solenoid valve or the valve core because of too many gas impurities.
- Q: Can machines share several cylinders?
A: It is also possible. One gas cylinder can be supplied to multiple machines, and multiple cylinders also can be supplied to one machine.
Moreover, we do not recommend that several machines share a single gas cylinder. The use time of a gas bottle is limited, so several machines sharing a cylinder will affect the presentation of the effect.
- Q: How long is the machine warranty?
A: The warranty is one year. If the machine is damaged and fails, please contact customer service the first time and provide your purchase order number and the video or appearance photos of the product work. We will start the after-sales maintenance service for you, and help you repair the machine perfectly. During the warranty period, replacement parts are shipped free of charge.
But two of the accessories have the following conditions. The warranty will be different.
- The connector is consumable. If the customer does not know how to use it, forced to connect these two connectors. It is very easy to damage the joint.
- The valve because the spool hole in the valve is very small, even if there are very small iron pieces or impurities in the gas, it will cause the plug of the spool. This situation belongs to the gas reason. So if you want to replace the accessories, the cost will have to be paid by the user.
For detailed information please refer to the Return Policy.
